四冲程 2.5 / 3.5 马力 · 共 17 个部位 / 357 条零件，点击零件编码查看详情，或搜索本页零件。
国产四冲程2.5匹马力消音罩69M-G2610-10-4D.jpg)
| REF | 零件编码 | 中文名称 | 英文名称 | 用量 | YMH对应零件号 |
|---|---|---|---|---|---|
| 1 | DM2509-G2610-000 | 消音罩 | TOP COWLING ASSY | 1 | 69M-G2610-10-4D |
| 2 | DM2509-G2613-000 | MOLDING, AIR DUCT | 1 | 69M-G2613-00 | |
| 3 | 13320-60098 | 自攻螺钉 | SCREW, TAPPING | 2 | 97780-40012 |
| 4 | DM2509-WG070-000 | 标贴 | GRAPHIC SET | 1 | 69M-WG070-00 |
| 5 | DM2509-G2677-000 | 标贴 | GRAPHIC, FRONT | 1 | 69M-G2677-00 |
| 6 | DM2509-G2678-000 | 标贴 | GRAPHIC, REAR | 1 | 69M-G2678-10 |
| 7 | DM2509-42662-000 | 减震块 | DAMPER | 1 | 69M-42662-00 |
| 8 | DM2509-13434-000 | 标贴 | LABEL, CAUTION | 1 | 67F-13434-02 |
| 9 | DM2509-14427-000 | 标贴 | LABEL, INSTRUCTION | 1 | 69M-14427-40 |
| DM2509-14427-001 | 标贴 | LABEL, INSTRUCTION | 1 | 69M-14427-50 | |
| 10 | DM0211-2415A-001 | 标贴 | LABEL, CAUTION | 1 | 6A1-2415A-41 |
| 11 | DM0211-2415A-002 | 标贴 | LABEL, CAUTION | 1 | 6A1-2415A-51 |
国产四冲程2.5匹马力发动机总成69M-WE090-00-4D.jpg)
国产四冲程2.5匹马力曲轴组合69M-11400-00.jpg)
| REF | 零件编码 | 中文名称 | 英文名称 | 用量 | YMH对应零件号 |
|---|---|---|---|---|---|
| 1 | DM2509-11400-000 | 曲轴组合 | CRANKSHAFT ASSY | 1 | 69M-11400-00 |
| 2 | 10809-87002 | 曲轴下端平垫圈 | WASHER, PLATE | 1 | 90201-23008 |
| 3 | DM2509-11650-000 | 连杆组合 | CONNECTING ROD ASSY | 1 | 69M-11650-00 |
| 4 | DM2509-11654-000 | 六角法兰面螺栓 | BOLT, CONNECTING ROD | 2 | 7FK-11654-00 |
| 5 | DM2509-E1631-000 | 活塞 | PISTON (STD) | 1 | 69M-E1631-01-96 |
| 6 | DM2509-E1603-000 | 活塞环组 | PISTON RING SET (STD) | 1 | 69M-E1603-01 |
| 7 | DM2509-E1633-000 | 活塞销 | PIN, PISTON | 1 | 69M-E1633-00 |
| 8 | 17650-97970 | 活塞销挡圈 | CIRCLIP | 2 | 93450-13130 |
国产四冲程2.5匹马力气缸体组合69M-E1311-00-1S.jpg)
国产四冲程2.5匹马力凸轮轴组件69M-12170-01.jpg)
| REF | 零件编码 | 中文名称 | 英文名称 | 用量 | YMH对应零件号 |
|---|---|---|---|---|---|
| 1 | DM2509-12170-000 | 凸轮轴组件 | CAMSHAFT ASSY 1 | 1 | 69M-12170-01 |
| 2 | DM2509-12111-000 | 进气门 | VALVE, INTAKE | 1 | 67D-12111-00 |
| 3 | DM2509-12121-000 | 排气门 | VALVE, EXHAUST | 1 | 67D-12121-00 |
| 4 | DM2509-12119-000 | 气门油封 | SEAL, VALVE STEM | 2 | 51Y-12119-00 |
| 5 | DM2509-E2113-000 | 气门弹簧 | SPRING, VALVE INNER | 2 | 68D-E2113-00 |
| 6 | DM2509-12117-000 | 气门弹簧座 | RETAINER, VALVE SPRING | 2 | 7NJ-12117-00 |
| 7 | DM2509-12118-000 | 气门弹簧卡圈 | COTTER, VALVE | 2 | 7NJ-12118-00 |
| 8 | DM2509-12151-000 | 气门摇臂 | ARM, VALVE ROCKER | 2 | 67D-12151-00 |
| 9 | DM2509-12165-000 | 摇臂轴 | PIVOT, ROCKER ARM | 2 | 7FK-12165-00 |
| 10 | DM2509-12158-000 | 气门锁紧螺母 | NUT, LOCK | 2 | 7FK-12158-00 |
| 11 | DM2509-12157-000 | 摇臂轴螺栓 | BOLT | 2 | 67D-12157-00 |
| 12 | DM2509-E2155-000 | 推杆导向板 | GUIDE, PUSH ROD | 1 | 69M-E2155-00 |
| 13 | DM2509-12154-000 | 推杆 | ROD, VALVE PUSH | 2 | 69M-12154-00 |
| 14 | DM2509-12153-000 | 挺柱 | LIFTER, VALVE | 2 | JA9-12153-00 |
国产四冲程2.5匹马力化油器放油软管69M-E4148-00.jpg)
| REF | 零件编码 | 中文名称 | 英文名称 | 用量 | YMH对应零件号 |
|---|---|---|---|---|---|
| 1 | DM2509-E4148-000 | 化油器放油软管 | PIPE | 1 | 69M-E4148-00 |
| 2 | 10645-99M90 | 扎带 | CLAMP | 1 | 90465-11M10 |
| 3 | DM2509-14440-000 | 进气消音器组件 | SILENCER ASSY, INTAKE | 1 | 69M-14440-01 |
| 4 | 17890-80M45 | 汽油泵O型圈 | O-RING | 1 | 93210-20M65 |
| 5 | 13515-04535 | 六角头螺栓 | BOLT | 2 | 97595-06575 |
| 6 | 18115-04400 | 平垫圈 | WASHER | 2 | 92995-06600 |
| 7 | 10723-047Y7 | 进气消音器衬套 | COLLAR | 2 | 90387-063Y3 |
| 8 | DM2509-E2483-000 | 呼吸软管 | PIPE 3 | 1 | 69M-E2483-00 |
| 9 | 10665-03205 | 进气消音器回油管 | HOSE (L70) | 1 | 90445-07805 |
| 10 | DM2509-E3645-000 | 化油器隔热垫 | GASKET, MANIFOLD 1 | 1 | 69M-E3645-A0 |
| 11 | DM2509-E3646-000 | 化油器垫片 | GASKET, MANIFOLD 2 | 1 | 69M-E3646-A0 |
| 12 | DM2509-E3647-000 | 隔热板 | GASKET, MANIFOLD 3 | 1 | 69M-E3647-00 |
| 13 | DM2509-F6330-000 | 阻风门拉杆 | STARTER CABLE ASSY | 1 | 69M-F6330-01 |
国产四冲程2.5匹马力化油器69M-14301-00.jpg)
国产四冲程2.5匹马力内油箱69M-F4111-00.jpg)
国产四冲程2.5匹马力起动器总成69M-15710-00.jpg)
| REF | 零件编码 | 中文名称 | 英文名称 | 用量 | YMH对应零件号 |
|---|---|---|---|---|---|
| 1 | DM2509-15710-000 | 起动器总成 | STARTER ASSY | 1 | 69M-15710-00 |
| 2 | DM2509-15714-000 | 起动盘 | DRUM, SHEAVE | 1 | 69M-15714-00 |
| 3 | DM2509-15741-000 | 起动盘棘爪 | PAWL, DRIVE | 2 | 69M-15741-00 |
| 4 | DM2509-15713-000 | 平面蜗卷弹簧 | SPRING, STARTER | 1 | 67D-15713-00 |
| 5 | DM2509-15705-000 | 驱动盘钢丝挡圈 | SPRING, DRIVE PAWL | 1 | 67D-15705-00 |
| 6 | DM2509-15735-000 | 驱动盘 | GUIDE, CAM | 1 | 69M-15735-00 |
| 7 | DM2509-15793-000 | 驱动盘自攻螺钉 | SCREW | 1 | 69M-15793-00 |
| 8 | DM2509-15739-000 | 起动器塑料垫片 | WASHER, THRUST | 1 | 69M-15739-00 |
| 9 | DM2509-15751-000 | 起动绳 | WIRE, STARTER (1.5M) | 1 | 69M-15751-00 |
| 10 | DM0511-15755-000 | 起动手柄 | HANDLE, STARTER | 1 | 6G1-15755-00 |
| 11 | DM0511-15779-000 | 起动手柄盖 | COVER | 1 | 6G1-15779-00 |
| 12 | DM2509-E5789-000 | 启动绳减震圈 | DAMPER | 1 | 69M-E5789-00 |
| 13 | 13515-04540 | 六角头螺栓和平垫圈组合件 | BOLT, WITH WASHER | 3 | 97595-06560 |
| 14 | DM2509-15762-000 | 起动器密封圈 | SEAL, RUBBER 2 | 1 | 69M-15762-00 |
| 15 | DM2509-24182-000 | 起动器橡胶条 | DAMPER, LOCATING 2 | 1 | 69M-24182-00 |
国产四冲程2.5匹马力飞轮69M-85650-00.jpg)
| REF | 零件编码 | 中文名称 | 英文名称 | 用量 | YMH对应零件号 |
|---|---|---|---|---|---|
| 1 | DM2509-85650-000 | 飞轮 | ROTOR ASSY | 1 | 69M-85650-00 |
| 2 | DM2509-85640-000 | CDI点火器 | T.C.I. UNIT ASSY | 1 | 69M-85640-00 |
| 3 | 10820-06M04 | 飞轮半圆键 | KEY, WOODRUFF | 1 | 90280-04M06 |
| 4 | 10930-90M77 | 飞轮螺母 | NUT | 1 | 90170-10M33 |
| 5 | 10809-905A8 | 飞轮螺母垫片 | WASHER, PLATE | 1 | 90201-105A2 |
| 6 | DM2509-15723-000 | 拉绳导轮 | PULLEY, STARTER | 1 | 69M-15723-00 |
| 7 | 10905-04M86 | 六角法兰面螺栓 | BOLT, FLANGE | 2 | 90105-06M24 |
| 8 | 10620-85949 | 高压包护圈 | GROMMET | 1 | 90480-25161 |
| 9 | 13015-04098 | 六角头螺栓 | BOLT | 1 | 97095-06012 |
| 10 | DM0511-82370-000 | 高压包帽 | PLUG CAP ASSY | 1 | 6E3-82370-21 |
| 11 | DM1511-82575-000 | 熄火开关组件 | ENGINE STOP SWITCH ASSY | 1 | 65W-82575-01 |
| 12 | DM1511-82556-000 | 应急熄火拉绳 | STOPPER | 1 | 682-82556-00 |
| 13 | DM1511-8257Y-000 | 应急熄火开关帽 | CAP | 1 | 689-8257Y-00 |
| 14 | 10664-04M10 | 拉索保护套 | HOSE | 1 | 90446-06M90 |
国产四冲程2.5匹马力前底座本体69M-G2711-00-4D.jpg)
国产四冲程2.5匹马力操纵手柄总成.jpg)
国产四冲程2.5匹马力换挡手柄69M-G4111-00.jpg)
| REF | 零件编码 | 中文名称 | 英文名称 | 用量 | YMH对应零件号 |
|---|---|---|---|---|---|
| 1 | DM2509-G4111-000 | 换挡手柄 | HANDLE, GEAR SHIFT | 1 | 69M-G4111-00 |
| 2 | 17890-01750 | 换挡转轴O型圈 | O-RING | 2 | 93210-09350 |
| 3 | 17505-94086 | 钢珠 | BALL | 1 | 93505-16024 |
| 4 | 10509-98208 | 换挡手柄压缩弹簧 | SPRING, COMPRESSION | 1 | 90501-12802 |
| 5 | DM2509-G4122-000 | 换挡手柄衬套 | BUSHING, SHIFT ROD LEVER | 1 | 68D-G4122-01 |
| 6 | DM2509-G4121-000 | 换挡臂 | LEVER, SHIFT ROD | 1 | 69M-G4121-00 |
| 7 | DM2509-44126-000 | 换挡臂垫片 | WASHER, SHIFT ROD LEVER | 1 | 69M-44126-00 |
| 8 | 13015-05098 | 六角头螺栓 | BOLT | 1 | 97095-05012 |
| 9 | 18115-05400 | 平垫圈 | WASHER | 1 | 92995-05600 |
| 10 | DM2509-44143-000 | 上换挡杆组件 | ROD, SHIFT | 1 | 69M-44143-00 |
| 11 | 18110-05400 | 平垫圈 | WASHER, PLATE | 1 | 92990-05600 |
| 12 | 19610-94090 | 开口销 | PIN, COTTER | 1 | 91490-16010 |
| 13 | DM2509-G4145-000 | 换挡杆右连接块 | CONNECTOR, SHIFT ROD | 1 | 6N0-G4145-10 |
| 14 | DM2509-G4146-000 | 换挡杆左连接块 | CONNECTOR, SHIFT ROD | 1 | 6N0-G4146-10 |
| 15 | 10991-04ME0 | 六角法兰面螺栓 | BOLT, WITH WASHER | 1 | 90119-06ME0 |
| 16 | DM0311-44144-000 | 下换挡杆 | ROD, SHIFT | 1 | 6L5-44144-00 |
| 17 | 19401-85096 | 弹性圆柱销 | PIN, SPRING | 1 | 91609-25014 |
国产四冲程2.5匹马力左支架69M-G3111-00-4D.jpg)
国产四冲程2.5匹马力中间箱体69M-G5111-00-4D.jpg)
| REF | 零件编码 | 中文名称 | 英文名称 | 用量 | YMH对应零件号 |
|---|---|---|---|---|---|
| 1 | DM2509-G5111-000 | 中间箱体 | CASING, UPPER | 1 | 69M-G5111-00-4D |
| 2 | DM0311-45151-000 | 中间箱体橡胶套 | COVER, UPPER CASING | 2 | 647-45151-01 |
| 3 | DM2509-G5152-000 | 操纵臂小盖 | COVER, UPPER CASING 2 | 1 | 69M-G5152-00 |
| 4 | 10951-05M98 | 十字槽盘头螺钉和平垫圈组合件 | SCREW, WITH WASHER | 1 | 90159-05M12 |
| 5 | DM2509-45113-000 | 动力下垫片 | GASKET, UPPER CASING | 1 | 69M-45113-A0 |
| 6 | 17406-98M03 | 水泵壳体定位销 | PIN, DOWEL | 2 | 93604-12M07 |
| 7 | 13535-04575 | 六角头螺栓和平垫圈组合件 | BOLT, WITH WASHER | 6 | 97575-06535 |
| 8 | 17300-04M07 | 油杯 | NIPPLE, GREASE | 1 | 93700-06M03 |
| 9 | DM2509-G5151-000 | 排气盖 | COVER, UPPER CASING | 1 | 69M-G5151-00 |
| 10 | DM2509-G5115-000 | 排气盖密封垫 | GASKET, UPPER CASING | 1 | 69M-G5115-00 |
| 11 | 10951-04M99 | 十字盘头螺钉和平垫圈组合件 | SCREW, WITH WASHER | 1 | 90159-06M11 |
| . |
国产四冲程2.5匹马力减速箱总成69M-G5300-00-4D.jpg)
国产四冲程2.5匹马力阳极68D-G5251-00.jpg)
| REF | 零件编码 | 中文名称 | 英文名称 | 用量 | YMH对应零件号 |
|---|---|---|---|---|---|
| 1 | DM2509-G5251-000 | 阳极 | ANODE | 1 | 68D-G5251-00 |
| 2 | 15215-04080 | 六角法兰面螺栓 | BOLT, FLANGE | 1 | 95895-06020 |
| 3 | 18110-04700 | 内锯齿锁紧垫圈 | WASHER, INTERNAL TOOTH | 1 | 92990-06300 |
| 4 | 17406-98M03 | 水泵壳体定位销 | PIN, DOWEL | 2 | 93604-12M07 |
| 5 | 13015-04070 | 六角头螺栓 | BOLT | 3 | 97095-06030 |
| 6 | 18115-04400 | 平垫圈 | WASHER | 3 | 92995-06600 |
| 7 | DM2509-44361-000 | 进水管 | TUBE, WATER | 1 | 69M-44361-00 |
| 8 | DM2509-G4365-000 | 进水管橡胶套 | DAMPER, WATER SEAL | 1 | 68D-G4365-00 |
| 9 | DM2509-G5987-000 | 螺旋桨推力衬套 | SPACER | 1 | 68D-G5987-00 |
| 10 | DM0311-45616-000 | 螺旋桨锁紧螺母 | NUT, PROPELLER | 1 | 6L5-45616-00 |
| 11 | 19610-85070 | 开口销 | PIN, COTTER | 1 | 91490-25030 |
| 12 | 10809-02M56 | 点火提前摆杆大垫圈 | WASHER, PLATE | 1 | 90201-08M54 |
| 13 | DM0311-45943-000 | 螺旋桨总成 | PROPELLER (3X7-1/4”X6”-BS) | 1 | 6L5-45943-00-EL |
| DM0311-45945-000 | 螺旋桨总成 | PROPELLER (3X7-1/4”X7-1/4”-BS) | 1 | 6L5-45945-00-EL | |
| DM0311-45947-000 | 螺旋桨总成 | PROPELLER (3X7-1/4”X8-1/4”-BS) | 1 | 6L5-45947-00-EL | |
| DM0311-45949-000 | 螺旋桨总成 | PROPELLER (3X7-1/4”X5”-BS) | 1 | 6L5-45949-00-EL | |
| DM0311-45952-000 | 螺旋桨总成 | PROPELLER (3X7-1/2”X5-1/2”-BS) | 1 | 6L5-45952-00-EL |
